Name: dx51d z100 steel sheet
SKU: 0

SHANDONG QUANQIU STEEL GROUP CO., LTD.

dx51d z100 steel sheet

Product Description

Product name	Galvanized steel sheet
Material	DX51D, DX52D, DX53D, DC51D, DC52D, DC53D, SGCC, SGCD, SGCE
Thickness	0.12-6.00mm or customers requirement
Width	600mm-1500mm, according to customer's requirement
Length	1-12m or as required
Type of coating	Hot Dipped Galvanized Steel
Surface Treatment	Clean,blasting and painting according to customer requirement.
Thickness tolerance	±0.15mm or as required
Export packing	Waterproof paper, and steel strip packed standard export seaworthy Package. suit for all kinds of transport, or as required.
Certificate	ISO9001/CE
MOQ	5ton

Material Property：	Specification	Material Property	Specification
Base Metal：	Carbon Steel (Low Alloy)	Tensile Strength (MPa)：	270-500
Surface Treatment：	Chromated, Oiled.Non-oiled	Yield Strength (MPa)：	140-340
Coating Thickness (μm)：	7-42	Hardness (HV)：	40-120
Coating Weight (g/m²)：	60-350	Length(mm)：	1000-6000
Zinc Coating：	Zinc (Galvanized)	Thickness (mm)：	0.25 -3.0
Zinc Coating Type：	Gl (Galvanized lron)	Width (mm)：	600-1250
Corrosion Resistance：	High, due to zinc coating	Melting Point of Zinc (°C)：	419.5
Density (g/cm³)：	7.14	Thermal Conductivity (w/m·k)：	116
Electrical Conductivity (S/m)：	1.69 x 10^7	Zinc Purity (%)：	99.95
Elongation (%)：	16-30	Application：	Construction，automotive,appliances
