Product Description


Product NameSteel I-Beams
WidthAccording to customer's requirement
ThicknessAccording to customer's requirement
LengthAccording to customer's requirement
TechniqueHot rolled / welding
Advantages1.low foundation cost2.easy construction3.time and labor saving
GradeA36/S235JR/S235/S355JR/S355, SS440/SM400A/SM400B, Q195,Q215,Q235B,Q345B, ETC
Product Application1.Building and Infrastructure: Main beams and columns in skyscrapers, industrial buildings, bridges, and mezzanines.
2.Heavy Equipment: Frames for trucks, cranes, and heavy machinery.
3.Residential Construction: Often used as the main support beam in basements or over large openings.

99d7eb4d236a6927ae0579397a93400e


S235 / Q235 / A36 / SS400 are often considered general-purpose equivalents.

S355 / Q355 / A992 / SM490 are often considered high-strength equivalents for primary structural members.

Standard SystemCommon GradesKey CharacteristicsTypical Applications
European (EN)S235JR, S235J0, S235J2Yield strength ≥235 MPa. Suffix indicates impact toughness at room temperature (JR), 0°C (J0), or -20°C (J2). Good weldability and formability.General construction, frames, supports.
S275JR, S275J0, S275J2Yield strength ≥275 MPa. Improved strength over S235 series with similar toughness grades.Medium-load bearing structures, industrial buildings.
S355JR, S355J0, S355J2, S355K2High-strength structural steel. Yield strength ≥355 MPa. K2 suffix indicates higher impact toughness. The most widely used grade for major structures.Bridges, high-rise buildings, heavy industrial plants.
American (ASTM/AISC)A36General-purpose carbon steel. Minimum yield strength 36 ksi (~250 MPa). Excellent weldability and ductility.Buildings, bridges, general construction.
A572 Grade 50High-strength low-alloy steel. Minimum yield strength 50 ksi (~345 MPa). Higher strength-to-weight ratio than A36.Heavy-duty structures, truck frames, transmission towers.
A992The preferred grade for structural shapes. Minimum yield strength 50 ksi (~345 MPa). Tight controls on chemical composition and mechanical properties (e.g., maximum yield strength, tensile-to-yield strength ratio).Modern building frames, seismic-resistant construction.
A588Weathering steel. Minimum yield strength 50 ksi. Forms a protective patina when exposed to weather, eliminating the need for painting. Excellent atmospheric corrosion resistance.Bridges, outdoor sculptures, exposed architectural elements.
Japanese (JIS)SS400General structural hot-rolled steel. Minimum tensile strength 400 MPa. No specified yield strength. Commonly used for general purposes.General frames, machinery, base plates.
SM490A, SM490B, SM490CWelded structural steel. Minimum tensile strength 490 MPa. "A, B, C" indicate different Charpy impact test requirements (C is the highest). Widely used for important welded structures.Building frames, bridges, ships, offshore structures.
SN400, SN490Rolled steels for building structures (designed for seismic applications). Grades are subdivided into A, B, C sub-categories with stricter requirements on yield ratio, elongation, and toughness.Beams and columns in earthquake-resistant buildings.

821037ba6bf2f433303dc376b343f910

Main brand chemical composition

Grade / StandardC (≤%)Mn (≤%)Si (≤%)P (≤%)S (≤%)Other Elements (Typical)
A360.260.90.40.040.05Cu ≥ 0.20 (min)*(*For shapes > 426 kg/m)
A9920.230.50-1.500.40.0350.045Cu ≥ 0.20 (min),V ≤ 0.11, Cb ≤ 0.06
S355JR0.241.60.550.0450.045Cu ≤ 0.55, N ≤ 0.014
S355J20.241.60.550.0350.035Cu ≤ 0.55, N ≤ 0.014
Q355B0.241.60.550.0350.035Cr ≤ 0.30, Ni ≤ 0.50,Cu ≤ 0.40
SM490YA0.21.60.550.0350.035Cu ≤ 0.55


Product application



product display



Packaging & Shipping

4579a76e1b40994ab7849d4a657e384a


ef8d1a739fb2af81514042251d5ab771
